Product Introduction

This equipment is designed for performance testing of large-scale hydraulic components (e.g., hydraulic supports, columns, and jacks) in coal mining and related industries. It adheres to relevant national standards for mining equipment testing and is capable of conducting a wide range of tests, including loading performance tests, sealing tests, and durability tests.

With flexible loading modes and a broad parameter adjustment range, it can meet the testing requirements of different specifications of hydraulic products. The equipment adopts advanced sensor data collection and digital display technology, ensuring high testing accuracy and reliable data. It also features a user-friendly operation interface and safety protection mechanisms, making it suitable for factory quality inspection, maintenance testing, and R&D verification of hydraulic components.

Technical Parameters

• Motor Power: 37 KW + 5.5 KW

• Test Pressure: 0 - 80 MPa

• Oil Pump Pressure: 0 - 32 MPa

• Vertical Loading Force: 10,000 KN - 40,000 KN

• Vertical Loading Method: Internal Loading (External Loading Device Optional)

• External Pump Flow Rate: 250 - 400 L/min

• Loading Width Range: 1,500 mm - 3,000 mm

• Loading Length Range: 4,000 mm - 8,000 mm

• Pressure Boost Ratio: 1:4

• Test Medium: 5% Emulsion

• Built-in Emulsion Pump Pressure: 0 - 6 MPa

• Built-in Emulsion Pump Flow Rate: 40 L/min

• Horizontal Loading Force: 4,000 KN - 8,000 KN

• Durability Test Cycles: > 100,000 Cycles

• Loading Height Range: 1,200 mm - 8,000 mm

• Pressure Boost Rate: 3 MPa/s
